1966 GT350 Trans & Shifter Details

Discussion in '1965-1970 Shelby Mustang GT350 & GT500' started by jchambers, Jan 21, 2010.

Page 1 of 2
  1. Jan 21, 2010 #1
    jchambers

    jchambers Member

    Posts:
    13
    Likes Received:
    0
    Joined:
    Jan 21, 2010
    I'm trying to determine the correct transmission and shifter combination for a 1966 Shelby GT350. The car is later in the delivery cycle, S2214 to be exact. The car currently has a top loader and I'm trying to determine if this would have been a T10 car originally. In terms of the shifter, was the Hurst standard equipment? Thanks so much.

    jchambers, Jan 21, 2010
    jchambers, Jan 21, 2010
    #1
  2. Jan 21, 2010 #2
    Texas Swede

    Texas Swede Well-Known Member

    Age:
    76
    Posts:
    520
    Likes Received:
    2
    Joined:
    Oct 11, 2005
    Location:
    Richardson, Texas
    Close Ratio T10 with either an aluminum case and tail shaft, cast iron
    on both or combination of cast iron and aluminum. My best guess
    will be a cast iron in both as your car is late in 66 production.
    Shifter is standard Ford Mustang with the Borg Warner rods, of course.
    Texas Swede

    Texas Swede, Jan 21, 2010
    Texas Swede, Jan 21, 2010
    #2
  3. Jan 21, 2010 #3
    jchambers

    jchambers Member

    Posts:
    13
    Likes Received:
    0
    Joined:
    Jan 21, 2010
    Thanks Swede. I located and rebuilt a cast iron/cast iron close ration (H-code) T10 from a car less than 100 S/N away. Talked with a pretty well established restoration shop last week that said the top loader might have been the original trans.....started sweating and shaking immediately:confused:

    Now the hard part. I have been completely unsuccessful at locating the correct T10 shift linkages and transmission levers. Anyone have a source for these?

    jchambers, Jan 21, 2010
    jchambers, Jan 21, 2010
    #3
  4. Jan 21, 2010 #4
    zrayr

    zrayr Well-Known Member

    Posts:
    446
    Likes Received:
    11
    Joined:
    Oct 30, 2005
    Location:
    TX
    have you contacted Jim Cowles ?

    http://s247533021.onlinehome.us/catalog/


    Z. Ray

    zrayr, Jan 21, 2010
    zrayr, Jan 21, 2010
    #4
  5. Jan 22, 2010 #5
    Texas Swede

    Texas Swede Well-Known Member

    Age:
    76
    Posts:
    520
    Likes Received:
    2
    Joined:
    Oct 11, 2005
    Location:
    Richardson, Texas
    Shifter and rods are available on ebay. $335.
    Texas Swede

    Texas Swede, Jan 22, 2010
    Texas Swede, Jan 22, 2010
    #5
  6. Jan 22, 2010 #6
    jchambers

    jchambers Member

    Posts:
    13
    Likes Received:
    0
    Joined:
    Jan 21, 2010
    I'll have to check that out!

    jchambers, Jan 22, 2010
    jchambers, Jan 22, 2010
    #6
  7. Jan 22, 2010 #7
    s2ms

    s2ms Well-Known Member

    Posts:
    282
    Likes Received:
    2
    Joined:
    Apr 13, 2007
    Location:
    PNW
    Jeff,

    I agree a cast iron close ratio T-10H is likely the correct original for S2214, I still have the same style original in 6S1757. If you have found one you are very fortunate as they are extremely rare.

    If for some reason the car originally came with a top loader I wonder if the Ford VIN is stamped on the bottom pad like it is for standard K-codes, might be worth a look.

    Dave

    s2ms, Jan 22, 2010
    s2ms, Jan 22, 2010
    #7
  8. Jan 22, 2010 #8
    jchambers

    jchambers Member

    Posts:
    13
    Likes Received:
    0
    Joined:
    Jan 21, 2010
    On the bottom pad of the toploader? I'll take a look. The toploader crosses to a 1965 Mustang hence I don't believe that it is correct for the car but with these things I guess anything is possible.

    The search for the T-10H was exhaustive....or should I say exhausting. We paid a pretty penny for it for this customer. It was in good condition though; a simple rebuild to freshen was all it needed.

    I have a T-10Q that the owner had intended to put in the car if we couldn't find the H-code. It has been rebuilt and is in very good condition if anyone is interested.

    jchambers, Jan 22, 2010
    jchambers, Jan 22, 2010
    #8
  9. Jan 27, 2010 #9
    Edward66GT350

    Edward66GT350 Well-Known Member

    Age:
    65
    Posts:
    126
    Likes Received:
    0
    Joined:
    Dec 26, 2004
    what does H code, Q code mean?
    ed

    Edward66GT350, Jan 27, 2010
    Edward66GT350, Jan 27, 2010
    #9
  10. Jan 27, 2010 #10
    66shelbynz

    66shelbynz Well-Known Member

    Posts:
    180
    Likes Received:
    0
    Joined:
    Aug 25, 2005
    Location:
    New Zealand (downunder)
    i have a T10H-1 (main housing) T10H-7B (tailshaft) gearbox in my very early 65 mustang fastback. It has just spat the dummy and needs a rebuild - we've taken it apart and the cluster gear which meshes with 3rd gear has lost one tooth and two others are cracked and the third gear dogteeth are absolutely worn but....... the rest of the box is pretty good.
    2 questions plse
    does anybody know where i can get a cluster gear 31 24 19 17
    a 28teeth 3rd gear and a quality rebuild kit from? and does anybody know where i could find the information to decode the numbers/letter on my T10 please?
    cheers.
    Graeme.

    66shelbynz, Jan 27, 2010
    66shelbynz, Jan 27, 2010
    #10
  11. Jan 27, 2010 #11
    66shelbynz

    66shelbynz Well-Known Member

    Posts:
    180
    Likes Received:
    0
    Joined:
    Aug 25, 2005
    Location:
    New Zealand (downunder)
    66shelbynz, Jan 27, 2010
    66shelbynz, Jan 27, 2010
    #11
  12. Jan 28, 2010 #12
    jchambers

    jchambers Member

    Posts:
    13
    Likes Received:
    0
    Joined:
    Jan 21, 2010
    Thanks Snelly. I found a source for the levers and rods from Ford Vintage Shifters.

    jchambers, Jan 28, 2010
    jchambers, Jan 28, 2010
    #12
  13. Mar 6, 2010 #13
    jchambers

    jchambers Member

    Posts:
    13
    Likes Received:
    0
    Joined:
    Jan 21, 2010
    Does anyone have a nice picture of the T10 trans installed in the car, or a diagram from a shop manual. The Comet/Fairlane/Mustang manual for 1966 doesn't cover the T10 installation. I want to make sure that I have the levers oriented correctly before installation. Also, the adjustment procedures would be helpful, but for the most part I would assume that they follow the same philosophy of the toploader and other four speeds of the era.

    Thanks Shelbyforums.

    jchambers, Mar 6, 2010
    jchambers, Mar 6, 2010
    #13
  14. Mar 6, 2010 #14
    66shelbynz

    66shelbynz Well-Known Member

    Posts:
    180
    Likes Received:
    0
    Joined:
    Aug 25, 2005
    Location:
    New Zealand (downunder)
    hi Jeff - flick me an email snelby@xtra.co.nz and i'll forward you a
    T10 service package document full of diagrams that i bought off
    ebay a while ago.

    Cheers
    Graeme.

    66shelbynz, Mar 6, 2010
    66shelbynz, Mar 6, 2010
    #14
  15. Mar 7, 2010 #15
    jchambers

    jchambers Member

    Posts:
    13
    Likes Received:
    0
    Joined:
    Jan 21, 2010
    Email sent. Thanks for the help.

    jchambers, Mar 7, 2010
    jchambers, Mar 7, 2010
    #15
  16. Mar 7, 2010 #16
    Coralsnake

    Coralsnake Well-Known Member

    Age:
    60
    Posts:
    1,048
    Likes Received:
    16
    Joined:
    Sep 8, 2004
    Location:
    The Northcoast
    I may know of a cast iron T10 that came out of a 65 Shelby. It was replaced with an aluminum one out of an original car. Email me and I will give you the lead.

    Pete

    Coralsnake68@hotmail.com

    Coralsnake, Mar 7, 2010
    Coralsnake, Mar 7, 2010
    #16
  17. Mar 7, 2010 #17
    66shelbynz

    66shelbynz Well-Known Member

    Posts:
    180
    Likes Received:
    0
    Joined:
    Aug 25, 2005
    Location:
    New Zealand (downunder)
    Thanks Pete - much appreciated . ive actually been able to find
    all the bits i needed to rebuild mine from a chap Bob Bartlett at
    www.fourgeartrans.com . He's been a top guy sourcing and
    obtaining for me a near new cluster, 3rd gear, quality rebuild
    kit and a 'how to rebuild a t10' instruction guide - well packaged
    and sent priority mail for just over $400 usd. I couldn't be happier
    My GT350 was auto but the T10 ive been looking for bits for is out of my
    early '65 Fastback but thanks again for your help. Hey love your
    own site and if only i could afford that '65 you rebuilt - great car !!

    cheers.

    66shelbynz, Mar 7, 2010
    66shelbynz, Mar 7, 2010
    #17
  18. Mar 9, 2010 #18
    jchambers

    jchambers Member

    Posts:
    13
    Likes Received:
    0
    Joined:
    Jan 21, 2010
    Got it all figured out. If you haven't had the opportunity to deal Bill Heely at Vintage Ford Shifters, I'll say that he has been a tremendous help. When no one else in the free world could come up with the T10 levers and rods, he came through with a perfect set. Then follows up with excellent customer service letting me bend his ear a bit.

    jchambers, Mar 9, 2010
    jchambers, Mar 9, 2010
    #18
  19. Mar 9, 2010 #19
    Texas Swede

    Texas Swede Well-Known Member

    Age:
    76
    Posts:
    520
    Likes Received:
    2
    Joined:
    Oct 11, 2005
    Location:
    Richardson, Texas
    I agree 100% about Bill. He has restored several shift levers for me
    and done an excellent job and not expensive either.
    Really a nice guy to deal with.
    Texas Swede

    Texas Swede, Mar 9, 2010
    Texas Swede, Mar 9, 2010
    #19
  20. May 1, 2010 #20
    jbarela

    jbarela Well-Known Member

    Posts:
    142
    Likes Received:
    0
    Joined:
    Apr 10, 2008
    were the 66 all cast iron transmissions painted black or natural in finish? main...tail..side cover??thanks guys..

    Jimmy

    jbarela, May 1, 2010
    jbarela, May 1, 2010
    #20
